Ana sayfa ÜrünlerÇok Jetli Su Sayacı

24 - 35V Supply Voltage Multi Jet Water Meter Wired Mbus Communicationfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage('en', 'tr', function () {});}

24 - 35V Supply Voltage Multi Jet Water Meter Wired Mbus Communicationfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage('en', 'tr', function () {});}

    • 24 - 35V Supply Voltage Multi Jet Water Meter Wired Mbus Communication
    • 24 - 35V Supply Voltage Multi Jet Water Meter Wired Mbus Communication
  • 24 - 35V Supply Voltage Multi Jet Water Meter Wired Mbus Communication

    Ürün ayrıntıları:

    Menşe yeri: Çin
    Marka adı: Lanhua
    Sertifika: ISO4064
    Model numarası:

    Ödeme & teslimat koşulları:

    Min sipariş miktarı: 1000
    Ambalaj bilgileri: Köpük kutu
    Teslim süresi: 4-8 hafta
    Ödeme koşulları: L/C, T/T
    Yetenek temini:
    İletişim
    Detaylı ürün tanımı
    Ürün türü: iletişim:
    Besleme gerilimi: EMC: E1
    Görüntüleme: No koruma: IP67
    Montaj: Yatay veya dikey Basınç:
    Çapı: : İsteğe bağlı
    Vurgulamak:

    multijet water meter

    ,

    Dry Dial water meter

    wired Mbus multi jet water meter, for AMR smart metering system Housing: brass or iron DN15-25



    Features

    • Low consumption microchips, low static power
    • Photo-electric reading
    • Quickly reading and transimitting within 0.3s
    • Protection: IP67
    • No need for external battery

    General Description



    The market demands on the inetegration of water meters, with modern remote reading systems is the ability of the meters to communicate. Our AMR-technology provides modular structured solutions for smart metering systems via suitable interfaces, adapted to individual customer requirements. Our portfolio inclueds bothe wired bus systems and wireless radio solutions, as well as the associated software for activation and for taking readings with the systems.



    Applications:

    Industrial and commercial water supply, volumetric water flow metering and automatic meter reading for utility, irrigation.



    FUNCTIONS

    1. Totally sealed design, waterproof.

    2. Automatically memorize the wheel code position and no need initiation.

    3. Avoiding external strong magnetic attack, high performance of anti-interference.

    4. Effectively solve the phenomenon of reversing and hammering.

    5. Adopting M-BUS communication port, which with long distance communication.

    6. No need power supply for daily work.

    7. With remote valve control function that can stop water supply remotely.



    The basic water meter Features:

    • The Nominal flowrate of Qn 1.5 m³/h to 15m³/h, Q3 2.5m³/h to 25m³/h
    • R value is R80 / 100 / 125 / 160 as requested
    • Suitable for both cold and warm water applications
    • Replaceable meter inserts available
    • Good readability even at extreme operational conditions
    • Optionally retrofittable with pulse contactors

    Water meter operate condition:

    • Water temperature:0.1℃~40℃ for cold water
      30℃~90℃ for hot water meter.
    • Water pressure: ≤1.0 Mpa

    Note:

    • Measuring accuracy conform to ISO 4064 class B standard..
    • Available with different length on request. Available in hot water meter on request.

    Maximum Permissible Error:

    (1) Between qt (included) and qs is ±2%;
    (2) Between qmin and qt (excluded) is ±5%.



    24 - 35V Supply Voltage Multi Jet Water Meter Wired Mbus Communicationfunction gtElInit() {var lib = new google.translate.TranslateService();lib.translatePage('en', 'tr', function () {});} 0

    TECHNICAL PARAMETERS

    Caliber(DN) 15mm 20mm 25mm
    Overload Flowrate (Q4) 3.125 m³/h 5 m³/h 7.875 m³/h
    Permanent Flowrate (Q3) 2.5 m³/h 4 m³/h 6.3 m³/h
    Transitional Flowrate (Q2) 0.05 m³ /h 0.08 m³/h 0.126 m³/h
    Minimum Flowrate (Q1) 0.0313 m³/h 0.05 m³/h 0.0788 m³/h
    Measurement Range (Q3/Q1) 80
    Minimum Reading 0.0001m³
    Maximum Reading 9999m³
    Measure Unit 1m³
    Working Temperature

    0.1℃~30℃(cold water)

    0.1℃~90℃(hot water)

    Communication Interface M-BUS
    Pressure Level â–³P63
    Working Pressure 0.03MPa~1MPa
    Flow Section Sensitivity Level U10, D5
    Climate and Mechanical Environment Safety Level B
    EMC E1









































    Competitive Advantage:

    • Compliance to international standards: ISO4064 / GBT778 / Q/320700JR05-2003
    • Strict process control
    • Advanced calibration equipment
    • Engineer team
